Overhead ceiling mounted shield (351)

  • Overhead ceiling mounted shield (351)
  • Overhead ceiling mounted shield (351)
  • Overhead ceiling mounted shield (351)
  • Overhead ceiling mounted shield (351)

Description

Transparent upper body radiation shield, with or without patient contour corner cut out.

Features:

  • Transparent lead acrylic, lead equivalent 0.5 mm.
  • Landscape orientation.
  • Patient contour corner cut out available for 60 cm x 80 cm shield only.
  • Flexible 0.5 mm lead panels available for lower profile.
  • Bespoke column lengths available on request.
  • Ceiling Column can be statically mounted to the ceiling or attached to a movable carriage in a ceiling track.

Installation options (note: physical installation of the product is not included)
Stationary system:
– 351 shield, suspension arm and fixed 80 cm ceiling column.
Ceiling track system:
– 351 shield, 250 cm ceiling track & moveable carriage, suspension arm and 80 cm column.
– 351 shield, 420 cm ceiling track & moveable carriage, suspension arm and 80 cm column.
Wall mounted system:
– 351 shield, suspension arm and wall fixing bracket.

351 shield
60 cm high x 80 cm wide.
60 cm high x 80 cm wide with patient contour corner cut-out.
40 cm high x 50 cm wide.
Optional flexible 0.5 mm lead panels fitted around lower profile.
