Pro-RF Contrast - radiography contrast detail phantom

  • Pro-RF Contrast - radiography contrast detail phantom
  • Pro-RF Contrast - radiography contrast detail phantom

Description

The Contrast-Detail (CD) phantom makes it possible to quantify both detail and contrast as observed by the radiologist. It can be used within the entire range of radiography diagnostic imaging systems, such as fluoroscopy and angiography. It has 405 holes that generate subtle changes in contrast.

Technical data (can be modified to customer specifications):

  • dimensions: 265 x 265 x 10 mm
  • made of PMMA
  • 15 columns and 15 rows of holes
  • two cylindrical holes for each combination, except for the first 3 rows with the largest diameters
  • diameters of holes range from 0.3 to 8.0 mm
  • depths of holes range from 0.3 to 8.0 mm
  • tolerance of hole measurements is at least 0.01 mm
  • all markings on the phantom are opaque for X-rays
  • available in rectangular and circular shapes
  • additional Cu filters for different attenuation combinations
  • optional carrying case (02-110)

Product features:

  • Complies with:
    – IEC 61223-3-1
  • CE certified
  • the Manual provides detailed guidelines for carrying out each test, results assessment and registration
