Description
This kit is a versatile set of phantoms and software for carrying out constancy tests of radiography x-ray units. Thanks to the Pro-Control.online subscription, all tests can be quickly and effortlessly automatically analysed online and with the desktop app.
Standard Kit Configuration:
• Pro-Digi (02-102)
• Pro-RF Al25 (02-303)
• Pro-RF Cu 1 (02-304)
• Pro-RF Rack (02-301)
• Pro-RF Stand (02-302)
• Pro-RF AEC Cu (02-203)
• Pro-Control.online BASIC annual subscription
• carrying case with dedicated foam inlay
The Kit can be used to measure:
• collimation/beam alignment
• position and size of the effective radiation field
• dynamic range
• spatial resolution
• contrast resolution
• homogeneity
• AEC tests
• dose reproducibility
Product Features
• complies with:
- IEC 61223-3-1
- DIN 6868/58 and DIN 6868/13
• CE certified
• the Manual provides detailed guidelines for carrying out each test, results assessment and registration
