Description
Phantom for acceptance and constancy testing of 3D function of dental Cone-Beam CT, Dental Volume Tomography (DVT) and 3D imaging devices according to DIN 6868-161 and QS-RL.
Technical data (can be modified to customer specifications):
- diameter: 160mm
- 20mm thick main module containing:
– test object containing equivalents of air, soft tissue and bone
– positioning markers
– bubble level - 20mm, 50mm and 60mm thick PMMA modules with positioning aids
- test stand with a table for placing the phantom in the test position
- folding base for test stand positioning on the X-ray unit’s chair
- convenient, portable case for storing and transporting the phantom
Product Features:
- complies with:
– DIN 6868-161
– QS-RL - CE certified
- the Manual provides detailed guidelines for carrying out each test, results assessment and registration
