Description
This kit is a versatile set of phantoms and software for carrying out constancy and acceptance tests of Intra-oral, OPG, CBCT, DVT and other 3D imaging devices. Thanks to the Diagnomatic subscription, all tests can be quickly and effortlessly automatically analysed online and with the desktop app.
Standard kit configuration:
- Pro-Dent set All (01-203)
- Pro-Dent CT MINI (01-303)
- Diagnomatic BASIC annual subscription
- carrying case with dedicated foam inlay
The kit can be used to measure:
- dose reproducibility
- development process stability
- alignment and beam geometry
- image geometry
- pixel (matrix) size
- artefacts, noise
- homogeneity
- linearity
- contrast
- low-contrast resolution (contrast sensitivity)
Product features:
- complies with:
- IEC 61223-3-4, IEC 61223-3-5 and IEC 61223-2-7
- DIN 6868-5 and DIN V 6868-151
- ÖNORM S 5240-5 and ÖNORM S 5240-11 - CE certified
- the Manual provides detailed guidelines for carrying out each test, results assessment and registration
