Description
3D Geometry Phantom™
Main Features:
* The phantom can be utilized to evaluate linearity and FOV accuracy in three dimensions.
* Leak-proof design allows filling of desired background material
* High quality, precision, and accurate construction used throughout
* The phantom physical specifications is described below including the registration lines.
Specifications:
Cylinder inside diameter: 21 cm
Cylinder outside diameter: 22.2cm
Flooded height inside: 21 cm
Cylinder outside Height: 23.4 cm
Hole spacing: 1.5 cm
Hole diameter: 0.3 cm
Plate thickness: 0.64 cm
# holes in X plate: 196
# holes in Y plate: 196
# holes in Z plate: 140
Registration lines: 15°intervals 0° to 75°
