Description
Table Mounted Lower body X-ray shield with optional detachable top shields
These lower body shields substantially reduce exposure to scatter radiation emanating from the table or patient’s body. The primary shield (312/DS-039/1) comprises a lightweight and durable structure, with middle link and pivotal arm supporting a flexible lead curtain. Optional semi-flexible top shields provide additional protection to the upper body.
Features:
- The shield easily mounts to either side of the table allowing the pivotal arm to always face the head end.
- A 55 cm wide attachment bracket slides onto a 25 mm high tableside accessory rail (max. 11 mm thick). The securing handle position allows it to overhang the rail end and be repositioned further along the table.
- Equipment controls can be mounted on the large integrated rail and grouped with others close by on the adjacent tableside rail.
- The heavy duty middle link has an automatic wear adjustment facility ensuring accurate joint friction which prevents unwanted curtain movement even when the table is tilted in any direction.
- The curtains flexible inner layer is bonded to its outer covering which results in an extremely strong, supple and easy to clean curtain. As the protective layer is not suspended separately in a cover (bag), it cannot tear or fall away inside unnoticed.
