Pro-Mam Mammography Accreditation Phantom

The phantom can test the performance of a mammographic system and its ability to image small structures similar to those found clinically: calcifications, fibrous calcifications in ducts and tumor masses.

Pro-MAM Accreditation Phantom complies with ACR guidelines (with a case).

Technical data (can be modified to customer specifications):

• dimensions: 102.0 x 108.0 x 44.0 mm
• simulates 42 mm compressed breast of average glandular/adipose composition
• total PMMA thickness: 36.75 mm
• wax insert:
  – thickness: 7.25 mm
  – nylon fibrils diameters: 1.56, 1.12, 0.89, 0.75, 0.54 and 0.40 mm
  – microcalcifications: 0.54, 0.40, 0.32, 0.24 and 0.16 mm Al₂O₃ specks
  – tumor-like masses: 2.00, l.00, 0.75, 0.50 and 0.25 mm thick
• 4mm thick PMMA contrast disc
• rotating support plate
• comfortable carrying case

Product features:

• Complies with:
  – IEC 61223-3-2
  – ACR Mammography Accreditation Program Requirements (May 4, 2012)
• CE certified
• the Manual provides detailed guidelines for carrying out each test, results assessment and registration
