VISI-X Field Position Analyser

Request Quote

Product Description


The Visi-X is a proven concept in Quality Control and Service. It is a cassette shaped instrument for checking the light and radiation field coincidence on X-ray equipment. The Visi-X can also be used for checking of the centering of the bucky tray.
After-glowing Phosphorus Screen

The Visi-X is based on a after-glowing phosphorus screen. Simply darken the X-ray room and place your Visi-X under the X-ray tube. Adjust the light field and make your exposure. The radiation field will immediately be visualized by the glow of the special phosphor compound. This afterglow will last for several minutes.

No Film and No Unnecessary Radiation

Misalignment down to ±1 mm will be clearly shown on the built-in scales. No film is needed; therefore, no time is lost going back and forth to the film developer.
When viewing ordinary intensifying screens you will expose yourself to unnecessary radiation. With the Visi-X, you do not have to be present in the X-ray room and therefore there is no radiation hazard.
