Description

Deluxe ECT phantom without protruding flange to simplify positioning

Main Applications:

  • For use with high spatial resolution SPECT and PET systems*
  • System performance evaluation (collimator, artifacts, calibration, reconstruction parameters)
  • Acceptance testing
  • Routine quality assurance and control
  • Evaluation of center-of-rotation error
  • Evaluation of non-uniformity artifact
  • Evaluation of changes of radius-of-rotation on spatial resolution
  • Evaluation of reconstruction filters on spatial resolution
  • Evaluation of attenuation and scatter compensation
  • Research
  • ACR recommended phantom

Specifications of Cylinder:

  • All clear material: PMMA
  • Cylinder inside diameter: ~ 209 mm
  • Cylinder inside height: ~ 186 mm
  • Cylinder wall thickness: ~ 6.4 mm
  • Volume – Empty: ~6.3 liters
  • Volume – with cold rod insert: ~ 5.5 liters
  • Volume with PET Lid & no insert: ~ 6.2 liters
  • Spheres make no significant change in volume

Specifications of Insert and Spheres

  • All clear material:PMMA
  • Rod diameters: 4.8, 6.4, 7.9, 9.5, 11.1 and 12.7 mm**
  • Height of rods: 8.8 cm
  • Solid sphere diameters: 9.5, 12.7, 15.9, 19.1, 25.4 and 31.8 mm
  • Height of center of spheres from base plate: 12.7 cm
  • Filler Caps: 7/16 - 20 × 38.1 mm long

**PET Lid available. See Flangeless Esser PET Phantom with fillable cylinders mounted to face plate.
