Beam Alignment Test Tool

Request Quote

Product Description


The Beam Alignment Test Tool Model 162A provides a simple test of the x-ray beam alignment. When used with the Collimator Test Tool, X-ray beam misalignments of 1 and 2% can be visualized without the need for measuring or calculating.

The test instrument is constructed of a plastic cylinder 6.3” high with 2 steel balls, 1 at each end. The steel balls are located directly above one another so that, when level and aligned, they will be superimposed on the radiograph. A bubble level is included so that accurate tests can be performed with ease.

Specifications RMI 162A:

  • CONSTRUCTION Acrylic cylinder
  • DIMENSIONS HEIGHT 16cm (6.3”)
  • DIAMETER 7cm (2.8”)
  • WEIGHT 260g (9.2 oz.)
